[Detection] Yolov4 custom dataset 학습방법(colab)

dohyeon2 2021. 7. 27. 13:54

import glob, os

# Current directory
current_dir = os.path.dirname(os.path.abspath(__file__))

print(current_dir)

current_dir = 'data/obj'

# Percentage of images to be used for the test set
percentage_test = 10;

# Create and/or truncate train.txt and test.txt
file_train = open('data/train.txt', 'w')
file_test = open('data/test.txt', 'w')

# Populate train.txt and test.txt
counter = 1
index_test = round(100 / percentage_test)
for pathAndFilename in glob.iglob(os.path.join(current_dir, "*.jpg")):
    title, ext = os.path.splitext(os.path.basename(pathAndFilename))

    if counter == index_test:
        counter = 1
        file_test.write("data/obj" + "/" + title + '.jpg' + "\n")
    else:
        file_train.write("data/obj" + "/" + title + '.jpg' + "\n")
        counter = counter + 1

yolov4/darknet/data/obj 폴더에 있는 데이터셋 파일들을 train.txt, test.txt 파일에 경로+파일이름 으로 내용삽입해주는 스크립트

여기까지 완료되면 다음과 같이 폴더가 구성되어야함 !!!!

7. makefile 수정(OpenCV, GPU 사용을 위한)

%cd darknet/
!sed -i 's/OPENCV=0/OPENCV=1/' Makefile
!sed -i 's/GPU=0/GPU=1/' Makefile
!sed -i 's/CUDNN=0/CUDNN=1/' Makefile
!sed -i 's/CUDNN_HALF=0/CUDNN_HALF=1/' Makefile
!sed -i 's/LIBSO=0/LIBSO=1/' Makefile

darknet build를 위한 명령어

!make

8. yolov4 폴더에 있는 파일들을 darknet 디렉토리로 복사

darknet/data 폴더 내 모든파일 삭제 + darknet/cfg 폴더 삭제

%cd data/
!find -maxdepth 1 -type f -exec rm -rf {} \;
%cd ..
%rm -rf cfg/
%mkdir cfg

darknet/data 폴더에 obj 폴더 생성하고 해당폴더에 데이터셋 압축풀기

!unzip /mydrive/yolov4/obj.zip -d data/obj

yolov4-custom.cfg 파일을 darknet/cfg 폴더에 복사

!cp /mydrive/yolov4/yolov4-custom.cfg cfg

obj.data, obj.names 파일을 darknet/data 폴더에 복사

!cp /mydrive/yolov4/obj.names data
!cp /mydrive/yolov4/obj.data  data

process.py 파일을 darknet 디렉토리에 복사

!cp /mydrive/yolov4/process.py .

process.py 파일 실행하여 train.txt, test.txt 파일 생성

!python process.py

9. pretrain된 yolov4 weight 파일 다운로드

여기서 전이학습을 사용합니다. 모델을 처음부터 훈련하는 대신 최대 137개의 convolution layer까지 훈련된 사전훈련 가중치 파일을 사용합니다.

!wget https://github.com/AlexeyAB/darknet/releases/download/darknet_yolo_v3_optimal/yolov4.conv.137

10. Training

본인의 custom training dataset을 미리 학습된 yolov4.conv.137 가중치 파일에 전이학습합니다

!./darknet detector train data/obj.data cfg/yolov4-custom.cfg yolov4.conv.137 -dont_show -map

만약 training중 예기치않게 학습이 중지되었다면

드라이브 마운트
makefile 수정
!make 로 darknet build

이 세가지만 다시 실행한다음에 다음의 명령어를 실행합니다

!./darknet detector train data/obj.data cfg/yolov4-custom.cfg /mydrive/yolov4/training/yolov4-custom_last.weights -dont_show -map

11. Test

imShow 함수 정의

# function imShow define
def imShow(path):
  import cv2
  import matplotlib.pyplot as plt
  %matplotlib inline

  image = cv2.imread(path)
  height, width = image.shape[:2]
  resized_image = cv2.resize(image,(3*width, 3*height), interpolation = cv2.INTER_CUBIC)

  fig = plt.gcf()
  fig.set_size_inches(18, 10)
  plt.axis("off")
  plt.imshow(cv2.cvtColor(resized_image, cv2.COLOR_BGR2RGB))
  plt.show()

yolov4-custom.cfg 파일에서 batch =1 ,subdivisions=1 로 수정

%cd cfg
!sed -i 's/batch=64/batch=1/' yolov4-custom.cfg
!sed -i 's/subdivisions=16/subdivisions=1/' yolov4-custom.cfg
%cd ..

1. 이미지에서 yolov4 detector 실행

먼저 mydrive 에 kickboard_test_images 폴더를 만들고 테스트 이미지 넣어주기!!

!./darknet detector test data/obj.data cfg/yolov4-custom.cfg /mydrive/yolov4/training/yolov4-custom_best.weights /mydrive/kickboard_test_images/image1.jpg -thresh 0.3
imShow('predictions.jpg')

2. video에서 yolov4 detector 실행

mydrive에 kickboard_test_videos 폴더 생성하고 테스트 비디오 넣기

!./darknet detector demo data/obj.data cfg/yolov4-custom.cfg /mydrive/yolov4/training/yolov4-custom_best.weights -dont_show /mydrive/mask_test_videos/test1.mp4 -thresh 0.5 -i 0 -out_filename /mydrive/kickboard_test_videos/results1.avi

3. live webcam에서 yolov4 detector 실행

# import dependencies
from IPython.display import display, Javascript, Image
from google.colab.output import eval_js
from google.colab.patches import cv2_imshow
from base64 import b64decode, b64encode
import cv2
import numpy as np
import PIL
import io
import html
import time
import matplotlib.pyplot as plt
%matplotlib inline


# import darknet functions to perform object detections
from darknet import *
# load in our YOLOv4 architecture network
network, class_names, class_colors = load_network("cfg/yolov4-custom.cfg", "data/obj.data", "/mydrive/yolov4/training/yolov4-custom_best.weights")
width = network_width(network)
height = network_height(network)

# darknet helper function to run detection on image
def darknet_helper(img, width, height):
  darknet_image = make_image(width, height, 3)
  img_rgb = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
  img_resized = cv2.resize(img_rgb, (width, height),
                              interpolation=cv2.INTER_LINEAR)

  # get image ratios to convert bounding boxes to proper size
  img_height, img_width, _ = img.shape
  width_ratio = img_width/width
  height_ratio = img_height/height

  # run model on darknet style image to get detections
  copy_image_from_bytes(darknet_image, img_resized.tobytes())
  detections = detect_image(network, class_names, darknet_image)
  free_image(darknet_image)
  return detections, width_ratio, height_ratio

# function to convert the JavaScript object into an OpenCV image
def js_to_image(js_reply):
  """
  Params:
          js_reply: JavaScript object containing image from webcam
  Returns:
          img: OpenCV BGR image
  """
  # decode base64 image
  image_bytes = b64decode(js_reply.split(',')[1])
  # convert bytes to numpy array
  jpg_as_np = np.frombuffer(image_bytes, dtype=np.uint8)
  # decode numpy array into OpenCV BGR image
  img = cv2.imdecode(jpg_as_np, flags=1)

  return img

# function to convert OpenCV Rectangle bounding box image into base64 byte string to be overlayed on video stream
def bbox_to_bytes(bbox_array):
  """
  Params:
          bbox_array: Numpy array (pixels) containing rectangle to overlay on video stream.
  Returns:
        bytes: Base64 image byte string
  """
  # convert array into PIL image
  bbox_PIL = PIL.Image.fromarray(bbox_array, 'RGBA')
  iobuf = io.BytesIO()
  # format bbox into png for return
  bbox_PIL.save(iobuf, format='png')
  # format return string

  return bbox_bytes

# JavaScript to properly create our live video stream using our webcam as input
def video_stream():
  js = Javascript('''
    var video;
    var div = null;
    var stream;
    var captureCanvas;
    var imgElement;
    var labelElement;

    var pendingResolve = null;
    var shutdown = false;

    function removeDom() {
       stream.getVideoTracks()[0].stop();
       video.remove();
       div.remove();
       video = null;
       div = null;
       stream = null;
       imgElement = null;
       captureCanvas = null;
       labelElement = null;
    }

    function onAnimationFrame() {
      if (!shutdown) {
        window.requestAnimationFrame(onAnimationFrame);
      }
      if (pendingResolve) {
        var result = "";
        if (!shutdown) {
          captureCanvas.getContext('2d').drawImage(video, 0, 0, 640, 480);
          result = captureCanvas.toDataURL('image/jpeg', 0.8)
        }
        var lp = pendingResolve;
        pendingResolve = null;
        lp(result);
      }
    }

    async function createDom() {
      if (div !== null) {
        return stream;
      }
      div = document.createElement('div');
      div.style.border = '2px solid black';
      div.style.padding = '3px';
      div.style.width = '100%';
      div.style.maxWidth = '600px';
      document.body.appendChild(div);

      const modelOut = document.createElement('div');
      modelOut.innerHTML = "<span>Status:</span>";
      labelElement = document.createElement('span');
      labelElement.innerText = 'No data';
      labelElement.style.fontWeight = 'bold';
      modelOut.appendChild(labelElement);
      div.appendChild(modelOut);

      video = document.createElement('video');
      video.style.display = 'block';
      video.width = div.clientWidth - 6;
      video.setAttribute('playsinline', '');
      video.onclick = () => { shutdown = true; };
      stream = await navigator.mediaDevices.getUserMedia(
          {video: { facingMode: "environment"}});
      div.appendChild(video);
      imgElement = document.createElement('img');
      imgElement.style.position = 'absolute';
      imgElement.style.zIndex = 1;
      imgElement.onclick = () => { shutdown = true; };
      div.appendChild(imgElement);

      const instruction = document.createElement('div');
      instruction.innerHTML =
          '<span style="color: red; font-weight: bold;">' +
          'When finished, click here or on the video to stop this demo</span>';
      div.appendChild(instruction);
      instruction.onclick = () => { shutdown = true; };

      video.srcObject = stream;
      await video.play();
      captureCanvas = document.createElement('canvas');
      captureCanvas.width = 640; //video.videoWidth;
      captureCanvas.height = 480; //video.videoHeight;
      window.requestAnimationFrame(onAnimationFrame);

      return stream;
    }
    async function stream_frame(label, imgData) {
      if (shutdown) {
        removeDom();
        shutdown = false;
        return '';
      }
      var preCreate = Date.now();
      stream = await createDom();

      var preShow = Date.now();
      if (label != "") {
        labelElement.innerHTML = label;
      }

      if (imgData != "") {
        var videoRect = video.getClientRects()[0];
        imgElement.style.top = videoRect.top + "px";
        imgElement.style.left = videoRect.left + "px";
        imgElement.style.width = videoRect.width + "px";
        imgElement.style.height = videoRect.height + "px";
        imgElement.src = imgData;
      }

      var preCapture = Date.now();
      var result = await new Promise(function(resolve, reject) {
        pendingResolve = resolve;
      });
      shutdown = false;

      return {'create': preShow - preCreate,
              'show': preCapture - preShow,
              'capture': Date.now() - preCapture,
              'img': result};
    }
    ''')

  display(js)

def video_frame(label, bbox):
  data = eval_js('stream_frame("{}", "{}")'.format(label, bbox))
  return data

# start streaming video from webcam
video_stream()
# label for video
label_html = 'Capturing...'
# initialze bounding box to empty
bbox = ''
count = 0
while True:
    js_reply = video_frame(label_html, bbox)
    if not js_reply:
        break

    # convert JS response to OpenCV Image
    frame = js_to_image(js_reply["img"])

    # create transparent overlay for bounding box
    bbox_array = np.zeros([480,640,4], dtype=np.uint8)

    # call our darknet helper on video frame
    detections, width_ratio, height_ratio = darknet_helper(frame, width, height)

    # loop through detections and draw them on transparent overlay image
    for label, confidence, bbox in detections:
      left, top, right, bottom = bbox2points(bbox)
      left, top, right, bottom = int(left * width_ratio), int(top * height_ratio), int(right * width_ratio), int(bottom * height_ratio)
      bbox_array = cv2.rectangle(bbox_array, (left, top), (right, bottom), class_colors[label], 2)
      bbox_array = cv2.putText(bbox_array, "{} [{:.2f}]".format(label, float(confidence)),
                        (left, top - 5), cv2.FONT_HERSHEY_SIMPLEX, 0.5,
                        class_colors[label], 2)

    bbox_array[:,:,3] = (bbox_array.max(axis = 2) > 0 ).astype(int) * 255
    # convert overlay of bbox into bytes
    bbox_bytes = bbox_to_bytes(bbox_array)
    # update bbox so next frame gets new overlay
    bbox = bbox_bytes
